Fluidyne V101 V101P3P2C20R Pump – 3 GPM, 0.60 in³/r, 2500 PSI, SAE ‘A’ 2-Bolt, Keyed Shaft – 100% Vickers V10 Replacement

Purchasing Information

Availability & Delivery

Most single stage vane pumps ship within 1-2 business days. Made-to-order items typically require 5-7 business days.

For current availability on V101P3P2C20R or other hydraulic pumps, call (800) 823-4937.

Warranty & Protection

• 12-month warranty covers manufacturing defects
• 30-day return window for unopened units
• Free technical verification before ordering
• Each pump pressure tested before shipment

Ordering Options

Order online for immediate processing. Phone orders welcome at (800) 823-4937.

Net 30 terms available for approved accounts.

Volume pricing available on orders of 4 or more units.

Support & Documentation

• Installation guide included with every shipment
• Technical drawings and specifications available
• Cross-reference guides for common brands
• Phone support: Monday-Friday, 7 AM – 5 PM MST. For technical resources and documentation, see our vane pumps technical library specifications.

Questions? Call our specialists: (800) 823-4937

Product Selection Guide

All five FluiDyne V101 single vane pump models listed share identical displacement (0.60 in³/r), flow (3 GPM at 1200 RPM), maximum pressure (2500 PSI), and SAE ‘A’ 2-bolt flange mounting. The key differences are in shaft type, rotation direction, and port orientation—critical for matching your application’s drive coupling, system rotation, and plumbing layout. All are Vickers replacement pumps applications, fully interchangeable, and covered by a 12-month warranty with same-day shipping on in-stock items.

Key Differences

Shaft Type

Difference: V101P3P2C20R and V101P3P0C20L024 use straight keyed shafts; V101P3P11A20L, V101P3P11A20R, and V101P3P11B20R use 9-tooth splined shafts.

Selection Guide: Choose keyed shaft models for standard or retrofit drives; select splined shaft models for higher torque applications or where coupling slippage is a concern. If your application requires pumps with integral valves, see our extended product range.

Rotation Direction

Difference: V101P3P2C20R, V101P3P11A20R, V101P3P11B20R are right-hand (clockwise); V101P3P0C20L024 and V101P3P11A20L are left-hand (counter-clockwise).

Selection Guide: Match pump rotation with your prime mover—right-hand for engines/motors with clockwise shafts, left-hand for counter-clockwise.

Port Position

Difference: V101P3P2C20R and V101P3P0C20L024 have ports inline (0°); V101P3P11A20L and V101P3P11A20R have ports opposite inlet (180°); V101P3P11B20R has ports 90° counter-clockwise from inlet.

Selection Guide: Choose inline ports for straight-through plumbing; 180° or 90° positions help in tight spaces or to avoid hose interference.

Quick Selection Guide

If you need: Standard keyed shaft, right-hand rotation, inline ports (0°)

Choose: V101P3P2C20R

Because: Best for typical clockwise shaft applications with direct or retrofitted couplings and straightforward plumbing.

If you need: Standard keyed shaft, left-hand rotation, inline ports (0°)

Choose: V101P3P0C20L024

Because: For systems needing counter-clockwise rotation with keyed coupling.

If you need: Splined shaft, left-hand rotation, 180° port position

Choose: V101P3P11A20L

Because: Ideal for high-torque, counter-clockwise drive systems with plumbing exiting opposite the inlet.

If you need: Splined shaft, right-hand rotation, 180° port position

Choose: V101P3P11A20R

Because: For high-torque, clockwise drive systems where outlet ports need to be opposite the inlet.

If you need: Splined shaft, right-hand rotation, 90° port position

Choose: V101P3P11B20R

Because: Best for high-torque, clockwise drive systems where space constraints require a 90° port arrangement. For other displacement options suited to similar applications, consider the V101B2B1C20R – FluiDyne V10 Pump.

Compatibility: All models are 100% interchangeable with Vickers V10 pumps, utilize SAE ‘A’ 2-bolt mounting, and feature 1″ NPT inlets and 1/2″ NPT outlets for direct fit and easy replacement. See our full lineup of single stage vane pumps for additional choices.

For help selecting the best V101 pump for your equipment or to ensure correct rotation, shaft, and port configuration, see similar products like the V101B3B0C20R024 – FluiDyne V10 Pump or call our hydraulic specialists at (800) 823-4937 (Mon-Fri, 7 AM – 5 PM MST). Volume pricing available on 4+ units.

Compatibility & Applications

Direct Replacement Information

The Fluidyne V101P3P2C20R is a direct, 100% interchangeable replacement for the Vickers V101P3P2C20R pump. Explore more about our Vickers replacement pumps for seamless integration. It is engineered for systems requiring 9.8 cm³/r (0.60 in³/r) displacement, 2500 PSI (172 bar) maximum pressure, and up to 1200 RPM rated speed..

• Mounting Pattern: SAE ‘A’ 2-bolt
• Inlet Port: G1″ BSPP
• Outlet Port: G1/2″ BSPP

Common Applications

Commonly used in mobile hydraulics applications, auxiliary power units, compact equipment.

• mobile hydraulics
• auxiliary power units
• compact equipment

Important: Verify pump model V101P3P2C20R matches your existing Vickers unit before ordering. If you need additional guidance, explore our vane pumps selection guide. For technical assistance, contact (800) 823-4937.
