Guardian 00205 Railmaster Rail Anchor

Description

Guardian Fall Protection

Railmaster Rail Anchor

The Guardian 00205 Railmaster turns a rail section into a compliant anchorage: it clamps to the rail profile and presents a connection point for one worker, purpose-built for track maintenance, rail yards, and transit work where structural steel is the rail itself.

Rated at 130 to 310 lbs including tools, the Railmaster meets OSHA 1926.502 and 1910.140 as the anchorage connector in a personal fall arrest system, with full documentation linked below.

130-420 lbs.Worker Capacity5,000 lbsTensile Strength3.7 lbsProduct WeightGalvanized SteMaterialOSHA 1910.140ComplianceOSHA 1926.502ComplianceGuardianLifetime Warranty1 DayUsual Ship Time

Who Needs This Product

Rail and transit contractors carry the Railmaster for bridge approaches, elevated track, and platform edges where the running rail is the only structure available. It installs without tools, anchors one worker, and moves down the track with the work. Pair it with an SRL or shock absorbing lanyard sized to the clearance below the deck.

Features

Corrosion-resistant zinc-plated steel constructi

Corrosion-resistant zinc-plated steel construction

For overhead or foot level tie-offs

For overhead or foot level tie-offs

Also available with Big Boss lanyard attached

Also available with Big Boss lanyard attached

Jobsite-grade construction

Built with the materials and finish quality Guardian applies across its height safety line.

Documented compliance

Full manufacturer documentation is linked on this page for submittal packages.

Fleet-friendly inspection

Clear inspection criteria in the manual keep competent-person checks fast and consistent.

Technical Specifications

SKU	00205
Worker capacity	130-420 lbs. including all clothing, tools, and equipment
Tensile strength	5,000 lbs
Materials	Galvanized Steel
Product weight	3.7 lbs
Dimensions	7 in L x 3 in W x 5.3 in H
Standards	OSHA 1910.140, OSHA 1926.502, ANSI Z359.18-2017
Warranty	Guardian lifetime warranty against defects in material and workmanship

⚠

Anchorage strength is the foundation of the system. The structure and anchor must withstand 5,000 lbs per attached worker or maintain a 2:1 safety factor under qualified-person supervision. Verify substrate, fastener, and orientation requirements against the instruction manual before every installation.

Compliance Standards

OSHA 1910.140

This product is compliant with OSHA 1910.140 when used as part of a complete, competent-person verified system.

OSHA 1926.502

This product is compliant with OSHA 1926.502 when used as part of a complete, competent-person verified system.

ANSI Z359.18-2017

This product is compliant with ANSI Z359.18-2017 when used as part of a complete, competent-person verified system.

ISO 17025 lab tested

Guardian products are tested in an ISO 17025 accredited laboratory; available documentation is linked below.

Typical Applications

Commercial constructionAnchorage for personal fall arrest during structural work.Residential constructionTie-off points for framing, roofing, and exterior trades.Plant maintenanceRecurring anchorage at tanks, racks, and platforms.Steel erectionConnection points during beam and decking work.Concrete workAnchorage during forming, placing, and finishing.Bridge and civilTie-off during inspection and rehabilitation.Solar installationAnchor points for install and service crews.Safety program standardizationOne anchor model and inspection routine across the company.

Installation Overview

Installation must follow the Guardian instruction manual for this anchor. The sequence below is an overview only.

1. Inspect first. Check the anchor body, connection point, and hardware before every installation.
2. Verify the structure. The supporting structure must meet the strength requirements in the instruction manual.
3. Install per the manual. Follow the substrate, fastener, and orientation requirements exactly; fill every required fastener position.
4. Verify the connection. Confirm the anchor is fully seated and the connection point is accessible and undamaged.
5. Connect the system. Attach a compatible connecting device and verify the complete personal fall arrest system with a competent person.
6. Check clearance. Confirm fall clearance below the work area and minimize swing fall hazards before work begins.

Inspection and Retirement

Inspect before every use, and have a competent person perform a documented inspection at least every six months under ANSI Z359.2 practice. Remove the anchor from service for any of the conditions below.

• Cracks, corrosion, or deformation of the body, connection point, or welds.
• Loose, missing, damaged, or worn hardware and fasteners.
• Elongation or wear at the D-ring or connection eye.
• Missing or illegible labels.
• Any evidence the anchor has arrested a fall.

Retirement triggers: any fall event on the anchor, or any condition where the inspector cannot positively verify it is fit for service.

Fall Protection
Distributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your SRL or lanyard setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Frequently Asked Questions

What rail profiles does the Railmaster fit?The Railmaster clamps common running rail profiles per the ranges in the instruction manual. Verify your rail section against the manual before ordering, and confirm the clamping surfaces are clean at each setup.Where is a rail anchor used?Elevated track, rail bridges, transit platforms, and yard structures where the rail is the available anchorage. The Railmaster gives those environments a compliant single-worker tie-off without welding or drilling.Does the anchor include a lanyard?No. The 00205 is the anchor only. Pair it with a compliant connecting device, an SRL for short fall distances or a shock absorbing lanyard where clearance allows, and verify the system with a competent person.Which standards does this product meet?It is compliant with OSHA 1910.140, OSHA 1926.502, ANSI Z359.18-2017 when used within a complete, competent-person verified fall protection system, and Guardian products are tested in an ISO 17025 accredited laboratory.What is the rated capacity?The rated worker capacity is 130-420 lbs., including all clothing, tools, and equipment carried by the worker.When should this product be retired?Retire it after any fall event, any failed inspection item, or whenever an inspector cannot positively verify it is fit for service. The inspection criteria in the linked documentation define the pass-fail conditions.Is documentation available for submittal packages?Yes. The manufacturer documentation linked on this page covers installation, specifications, and compliance, and every file is hosted on our site for direct download into your submittal package.

Guardian 00205 Railmaster Rail Anchor Submittals and Documentation

Guardian 00205 Manual (PDF)Installation, use rules, and inspection criteria from the manufacturer.Guardian 00205 Tds (PDF)Dimensions, materials, capacities, and the full compliance summary.Guardian 00205 Inspection Form (PDF)Printable competent-person inspection checklist.
