Miller 417 Permanent D-Bolt Concrete Anchor

Description

Miller Fall Protection

Permanent D-Bolt Concrete Anchor

The 417 is the set-and-forget concrete anchor: a drop-forged alloy steel D-bolt that installs through up to 4 inches of concrete and stays as a permanent, 5,000 lb rated tie-off point wherever recurring work needs one.

The single D-ring configuration gives one worker a dedicated anchorage that outlives the project.

5,000 lbTensile Rating4 inMax Working ThicknessForgedAlloy SteelPermanentInstallation1D-Ring PointConcreteApplicationOSHACompliant1944Miller Heritage

Who Needs This Product

Permanent anchors pay for themselves wherever the same tie-off gets rigged repeatedly: rooftop units, loading areas, and plant access points. The 417 bolts through once and ends the daily strap-hunting, with forged steel built to weather for years.

Features

Drop-Forged Alloy Steel

Forged construction withstands harsh conditions and years of exposure.

Through-Bolt Design

Installs through up to 4 inches of concrete for a positive structural connection.

5,000 lb Tensile

Meets the OSHA anchorage number without engineering paperwork.

Single-Point Discipline

One D-ring, one worker, one clean system per anchor.

Low Profile

Stays out of the way between uses.

Permanent Value

Ends the daily temporary-anchor rigging at recurring work points.

Technical Specifications

SKU	417
Product	Permanent D-Bolt Anchor
Material	Drop-forged alloy steel
Working thickness	Up to 4 in concrete
Rating	5,000 lb tensile
Standards	Meets OSHA anchorage requirements
Warranty	Miller Limited Lifetime Warranty against defects in workmanship and materials

⚠

The anchor is only as good as the structure. Connect only to members that meet OSHA anchorage strength, position to minimize free fall and swing, and inspect before every use.

Compliance Standards

OSHA 1926.502 Anchorage

Anchorages for fall arrest must support 5,000 lb per worker attached, or maintain a safety factor of two under a qualified person.

ANSI Z359 Practice

Anchorage connectors follow ANSI Z359 component practice with 5,000 lb rated hardware.

ANSI Z359.2

Kept in service through pre-use checks and documented competent person inspections at least annually.

Typical Applications

General construction fall arrest anchorage.Steel, concrete, and structural work.Roofing and elevated maintenance.Utility and industrial tie-off points.Temporary anchorage that moves with the crew.Completing the ABC system with Miller body wear and connectors.

Setup Overview

1. Inspect the anchor and hardware before use.
2. Select structure that meets OSHA anchorage strength for fall arrest.
3. Install the anchor per the instructions for the structure type.
4. Connect the lanyard or SRL and verify gates lock.
5. Verify fall clearance and swing fall exposure before working.

Full installation instructions ship with the product.

Inspection and Retirement

Inspect before each use and have a competent person inspect at least annually per ANSI Z359.2.

• Webbing or body: cuts, frays, corrosion, cracks, distortion, or damage.
• D-rings and hooks: no cracks, corrosion, distortion; gates lock where fitted.
• Stitching and fasteners: intact and tight.
• Labels: present and legible.

Retirement triggers: any fall arrest loading, any defect found during inspection, or failure to verify fitness for service.

Fall Protection
Distributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your SRL or lanyard setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Frequently Asked Questions

How does the 417 install?Through-bolted in concrete up to 4 inches working thickness per the instructions, by or under the supervision of a qualified person.Is it rated for fall arrest?Yes: 5,000 lb tensile, meeting the OSHA anchorage strength requirement for one attached worker.Can two workers share it?No. One personal fall arrest system per anchor point unless a qualified person has engineered otherwise.Where is it used?Recurring tie-off points: rooftop equipment, loading areas, and plant maintenance positions.Does it need engineering?Installation should be specified or supervised by a qualified person confirming the base concrete takes the load.How does it weather?The forged alloy construction is built for permanent outdoor exposure; inspection catches corrosion before it matters.How often does it need inspection?Before each use plus documented annual inspection, like any anchorage connector.
