MSA Workman 10102686 Reusable Roof Anchor, Galvanized

Description

MSA Safety Fall Protection

Workman 10102686 Reusable Roof Anchor, Galvanized

Stay safe while working on roofs Available in permanent or reusable models, roof anchors provide an anchor point for personal fall arrest systems on roofs for maintenance work, repair, and new construction.

This listing: Workman reusable roof anchor.

000 lbWeight Capacity3 lbShip WeightMSASafety Brand

Who Needs This Product

Stay safe while working on roofs Available in permanent or reusable models, roof anchors provide an anchor point for personal fall arrest systems on roofs for maintenance work, repair, and new construction.

Features

Center holes are offset

Center holes are offset to reduce possibility of truss splitting during installation

Can be used with screws or

Can be used with screws or nails

Can be used off roof peak

Can be used off roof peak in flat position without compromising strength

Technical Specifications

SKU	10102686
Product	Workman reusable roof anchor
Length	10.630 In (270.000 Mm)
Height	0.394 In (10.000 Mm)
Weight	1.543 Lb (0.700 Kg)
Width	5.906 In (150.000 Mm)
Shipping weight	3 lb
Warranty	MSA Express Warranty, one year from first use or 18 months from shipment

⚠

Safety first. Inspect before every use and remove this equipment from service immediately after any fall arrest event or failed inspection.

Compliance Standards

OSHA 1926.502 and 1910.140

Meets OSHA personal fall protection requirements for construction and general industry when used within a compliant system.

Anchorage Strength

OSHA requires non-certified fall arrest anchorages to sustain 5,000 lbf per attached worker, or two times maximum arresting force when designed by a qualified person.

Typical Applications

Construction.General Industry.Oil & Gas.Utilities.

Setup Overview

1. Inspect all components before each use.
2. Verify compatibility with your harness, anchorage, and connecting device.
3. Install or connect per the MSA instruction manual.
4. Verify all gates, buckles, or fasteners are closed and locked.
5. Confirm fall clearance and rescue plan before work begins.

Full use instructions are in the MSA documentation linked below.

Inspection and Retirement

Inspect before each use and have a competent person perform documented periodic inspections per the applicable ANSI standard and MSA instructions.

• Webbing and stitching: cuts, frays, burns, abrasion, UV fading, chemical damage.
• Hardware: cracks, corrosion, distortion; gates and buckles close and lock.
• Labels: present and legible.
• Function: retraction, braking, or adjustment operates smoothly as applicable.
• Impact indicators: any deployment means immediate removal from service.

Retirement triggers: any fall arrest event, failed inspection, deployed impact indicator, or illegible labels.

Fall Protection
Distributors, LLC Free Tool · No Signup · OSHA 1926.502 Free Interactive Tool Fall Protection Calculator Pick your system. Run the math. Generate a plan. 1Pick Your SystemDetermine fall restraint vs. fall arrest based on your work surface, edge access, and clearance. 2Run the MathCalculate exact fall clearance required below the work surface for your SRL or lanyard setup. 3Generate a PlanGet a printable OSHA-compliant Fall Protection Plan structured around 29 CFR 1926.502(k). Run the Numbers and Stay Safe Launch the Calculator ›

Frequently Asked Questions

What is the MSA 10102686?The Workman reusable roof anchor is an MSA anchorage connector built for commercial fall protection programs and certified to ANSI/OSHA.What is it used for?Typical applications include .What standards apply?It is certified to ANSI/OSHA.How do I inspect it?Inspect before each use for wear, corrosion, distortion, cuts, or damage, and have a competent person perform documented periodic inspections per the MSA instructions.When should it be retired?Remove it from service after any fall arrest loading, failed inspection, or visible damage. When in doubt, tag it out and replace.Does MSA warranty this product?Yes. MSA’s Express Warranty covers mechanical defects and faulty workmanship for one year from first use or 18 months from shipment, whichever comes first. Full terms are on the Warranty tab.Who should I call with application questions?Call Fall Protection Distributors at 863-703-4522 and we will confirm the right MSA equipment for your anchor points, crew, and jobsite, based on the delivery location.

MSA 10102686 Submittals and Documentation

Data Sheet Workman Reusable Roof Anchor (PDF)Official MSA document for this product family.Instruction Manual Workman Reusable Roof Anchor (PDF)Official MSA document for this product family.Instruction Manual Permanent Roof Anchor (PDF)Official MSA document for this product family.10102686 Anchor Inspection Form (PDF)Printable pass/fail checklist for documented inspections.
