Two 6″ Handi-Grip Hand Cups for Flat and Curved Surfaces

Description

Wood’s Powr-Grip TL6HG2B — 6″ Aluminum Handi-Grip Vacuum Hand Cups for Flat and Curved Surfaces (70 lbs / 32 kg per Cup) — Matched Pair of 2 with Carrying Case

The Wood’s Powr-Grip TL6HG2B is a matched pair of 6″ aluminum Handi-Grip vacuum hand cups designed for versatile lifting and positioning of a wide variety of flat and curved smooth, nonporous materials — including windshields, stone tiles, and sheet materials. Each cup features a 6″ (15 cm) standard rubber suction pad (Model TL6), an aluminum Handi-Grip handle, and an industrial-grade plastic plunger, with a rated load capacity of 70 lbs (32 kg) per cup. Rated for both flat and curved surfaces with a minimum radius of 12″ (305 mm), and operable down to 0°F (-18°C). Sold as a matched pair of 2 (SKU: 91344, Model: TL6HG) with a durable carrying case. Manufactured by Wood’s Powr-Grip.

The TL6HG2B is the matched-pair configuration of the TL6HG and the flat+curved counterpart to the LP6HG2B. The critical differentiator between the TL6HG2B and the LP6HG2B is surface compatibility: the TL6HG2B uses the TL6 pad and is rated for both flat and curved surfaces (min. 12″ radius), while the LP6HG2B uses the LP6 pad and is rated for flat surfaces only. Both use the same Handi-Grip handle geometry, 70 lb capacity, 0°F rating, and matched pair with carrying case configuration. Choose the TL6HG2B when your application includes curved surfaces such as windshields, curved glass, or curved stone; choose the LP6HG2B for flat-only applications.

Key Features & Benefits

Aluminum Handi-Grip Handle — Versatile Positioning Across Flat and Curved Materials

The Handi-Grip handle provides ergonomic control for comfortable, precise positioning of windshields, stone tiles, sheet materials, and other flat and curved smooth nonporous items. The Handi-Grip geometry is optimized for versatile positioning where the operator needs natural hand control across different material types, sizes, and surface curvatures. The aluminum construction is lightweight and corrosion-resistant in wet and outdoor environments.

Flat and Curved Surface Compatibility — Min. 12″ Radius — Key Differentiator vs. LP6HG2B

The TL6HG2B is rated for both flat and curved smooth, nonporous surfaces with a minimum curved surface radius of 12″ (305 mm). This flat+curved rating is the primary differentiator from the LP6HG2B (flat only) and makes the TL6HG2B the correct choice for windshields, curved glass, curved stone, and curved architectural elements within the 70 lb per cup capacity. If your application is flat surfaces only, the LP6HG2B is an equivalent option.

TL6 Pad — 6″ Standard Rubber — Not Interchangeable with LP6

The TL6HG2B uses the TL6 standard rubber pad (6″ diameter). The TL6 pad is a different pad model from the LP6 (used on LP6HG2B and LP6RH2B) — replacement pads must be specified as TL6 when ordering. Replacement TL6 pads are available separately through Wood’s Powr-Grip authorized distributors.

Matched Pair of 2 with Durable Carrying Case

The TL6HG2B provides two matched TL6HG cups with a durable carrying case, keeping the pair together and protected during transport. The matched pair is designed for two-person coordinated lifts (one cup per operator) or as a dedicated two-cup field kit for installers who handle both flat and curved materials.

70 lb (32 kg) Per Cup — 140 lb Combined — 0°F Rating

Each cup is rated for 70 lbs (32 kg), giving a combined capacity of 140 lbs (64 kg) for a coordinated two-cup lift. Rated for operation down to 0°F (-18°C). Red-line indicator warns of any significant vacuum loss.

Common Applications

Windshield and Curved Automotive Glass Handling

Auto glass technicians use the TL6HG2B to position windshields and curved automotive glass during installation and replacement. The flat+curved rating (min. 12″ radius) covers the majority of automotive windshield curvatures, and the Handi-Grip handle provides comfortable control during precise placement.

Stone Tile and Sheet Material Positioning

Tile setters and stone installers use the TL6HG2B for flat and curved stone tile, decorative stone, and sheet material handling where the Handi-Grip provides ergonomic control during precise placement.

Curved Glass and Architectural Glass Handling

Glaziers handling curved glass panels, curved storefront glass, and curved architectural elements use the TL6HG2B where the 12″ minimum radius and flat+curved rating cover the application and the matched pair provides a two-cup field kit.

Two-Person Coordinated Lifts on Flat and Curved Panels

The matched pair configuration supports two-person coordinated lifts where each operator holds one cup. Always lift and lower simultaneously on a coordinated signal.

Compatible Materials

• Automotive windshields and curved automotive glass (min. 12″ radius)
• Flat and curved plate glass and float glass
• Tempered and laminated safety glass (flat and curved, min. 12″ radius)
• Stone tile and polished stone panels (flat and curved)
• Glazed ceramic and polished porcelain tile (flat)
• Acrylic sheet, polycarbonate, and smooth metal panels (flat and curved)
• Any smooth, nonporous flat or curved surface with min. 12″ (305 mm) radius and load ≤ 70 lbs per cup

Not compatible with: rough, textured, or porous surfaces; surfaces with radius tighter than 12″ (305 mm); loads exceeding 70 lbs per cup; surfaces contaminated with oil, wax, or debris.

Technical Specifications

Specification	Details
Model	TL6HG
SKU	91344
Vendor	Wood’s Powr-Grip
Pack Quantity	2 cups (matched pair)
Load Capacity	70 lbs [32 kg] per cup / 140 lbs [64 kg] combined
Pad Diameter	6″ [15 cm]
Pad Model	TL6
Rubber Type	Standard
Handle Type	Aluminum (Handi-Grip)
Plunger Type	Industrial-Grade Plastic
Surface Texture Required	Smooth
Material Porosity Required	Nonporous
Allowable Surface Curvature	Flat and Curved
Minimum Radius for Curved Loads	12″ [305 mm]
Maximum Elevation	5,000 ft [1,500 m]
Operating Temperature Range	0°F to 120°F [-18°C to 49°C]
Vacuum Loss Indicator	Yes (red-line) — one per cup
Includes	Durable carrying case (fits both cups)

Safety Data Summary

• Always lift and lower simultaneously on a coordinated signal when using both cups on a single panel — uncoordinated lifting can overload one cup beyond its 70 lb rating
• Vacuum loss during a lift can result in sudden load drop, causing serious injury or property damage
• Do not exceed 70 lbs (32 kg) per cup
• Do not use on surfaces with radius tighter than 12″ (305 mm)
• Damaged or contaminated suction pads must be replaced before use
• In cold environments, verify pad flexibility above 0°F (-18°C) before use
• Do not use above 5,000 ft (1,500 m) elevation
• Safety glasses or face shield, cut-resistant gloves, and steel-toed footwear required

Frequently Asked Questions

Q: What is the difference between the TL6HG2B and the LP6HG2B?
A: Both are matched pairs of 2 Handi-Grip cups with carrying cases, 70 lb per cup capacity, 0°F rating, and aluminum handle + plastic plunger construction. The critical difference is surface compatibility and pad model: the TL6HG2B uses the TL6 pad and is rated for both flat and curved surfaces (min. 12″ radius); the LP6HG2B uses the LP6 pad and is rated for flat surfaces only. TL6 and LP6 replacement pads are not interchangeable. Choose the TL6HG2B when your application includes curved surfaces; choose the LP6HG2B for flat-only applications.

Q: What replacement pad does the TL6HG2B use?
A: The TL6HG2B uses the TL6 standard rubber pad (6″ diameter). This is a different pad from the LP6 (used on LP6HG2B and LP6RH2B) — do not substitute LP6 pads. Replacement TL6 pads are available separately through Wood’s Powr-Grip authorized distributors.

Q: Is this product made to order?
A: Yes. This product is made to order and all sales are final. Please confirm your surface type, curvature radius, load requirements, and operating environment before placing your order.
