Two 6″ Handi-Grip Hand Cups for Flat Surfaces

Description

Wood’s Powr-Grip LP6HG2B — 6″ Aluminum Handi-Grip Vacuum Hand Cups for Flat Surfaces (70 lbs / 32 kg per Cup) — Matched Pair of 2 with Carrying Case

The Wood’s Powr-Grip LP6HG2B is a matched pair of 6″ aluminum Handi-Grip vacuum hand cups designed for versatile lifting and positioning of a wide variety of flat smooth, nonporous materials — including windshields, stone tiles, and sheet materials. Each cup features a 6″ (15 cm) standard rubber suction pad (Model LP6), an aluminum Handi-Grip handle, and an industrial-grade plastic plunger, with a rated load capacity of 70 lbs (32 kg) per cup on flat surfaces. Operable down to 0°F (-18°C). Sold as a matched pair of 2 (SKU: 91337, Model: LP6HG) with a durable carrying case. Manufactured by Wood’s Powr-Grip.

The LP6HG2B is the matched-pair configuration of the LP6HG — the same cup sold as a Pack of 4 (SKU: 91335). The two-cup matched pair with carrying case is designed for two-person coordinated lifts where each operator uses one cup, or as a dedicated two-cup field kit. The carrying case keeps both cups together and protected during transport. All LP6HG specifications — pad, capacity, handle geometry, temperature rating — are identical between the LP6HG2B and the LP6HG Pack of 4.

Key Features & Benefits

Aluminum Handi-Grip Handle — Versatile Positioning Across a Wide Range of Materials

The Handi-Grip handle provides ergonomic control for comfortable, precise positioning of windshields, stone tiles, sheet materials, and other flat smooth nonporous items. Unlike the offset fixed handle (which prevents load swing), the Handi-Grip is optimized for versatile positioning where the operator needs natural hand control across different material types and sizes. The aluminum construction is lightweight and corrosion-resistant in wet and outdoor environments.

Windshield, Stone Tile, and Sheet Material Handling

The LP6HG2B is specifically suited for windshields and automotive glass, stone tiles and decorative stone, and general flat sheet materials — the same three material categories as the LP6HG Pack of 4, now in a matched two-cup field kit configuration.

Matched Pair of 2 with Durable Carrying Case

The LP6HG2B provides two matched LP6HG cups with a durable carrying case, keeping the pair together and protected during transport. The matched pair is designed for two-person coordinated lifts (one cup per operator) or as a dedicated two-cup field kit. The carrying case is the key packaging differentiator between the LP6HG2B and the LP6HG Pack of 4 (which ships with vacuum pad protectors).

70 lb (32 kg) Per Cup — 140 lb Combined — LP6 Pad — 0°F Rating

Each cup is rated for 70 lbs (32 kg), giving a combined capacity of 140 lbs (64 kg) for a coordinated two-cup lift. Uses the LP6 standard rubber pad (6″ diameter) — shared with the LP6RH and LP6RH2B, making replacement pads interchangeable across all LP6 family models. Rated for operation down to 0°F (-18°C). Red-line indicator warns of any significant vacuum loss.

Common Applications

Two-Person Coordinated Flat Panel Lifts

The matched pair configuration supports two-person coordinated lifts where each operator holds one cup at opposite ends of a flat panel. Always lift and lower simultaneously on a coordinated signal — uncoordinated lifting can overload one cup beyond its 70 lb rating.

Windshield and Automotive Glass Handling

Auto glass technicians use the LP6HG2B to position windshields and flat automotive glass during installation and replacement. The Handi-Grip handle provides comfortable control during precise placement work.

Stone Tile and Sheet Material Positioning

Tile setters, stone installers, and fabricators use the LP6HG2B for flat stone tile, decorative stone, and sheet material handling where the Handi-Grip provides ergonomic control during precise placement.

Cold Weather and Outdoor Job Sites

The 0°F cold rating and aluminum handle’s corrosion resistance make the LP6HG2B suitable for outdoor winter construction and wet environments.

Compatible Materials

• Flat automotive windshields and flat glass
• Flat plate glass and float glass
• Tempered and laminated safety glass (flat)
• Stone tile and polished stone panels (flat)
• Glazed ceramic and polished porcelain tile (flat)
• Acrylic sheet, polycarbonate, and smooth metal panels (flat)
• Any smooth, nonporous flat surface with load ≤ 70 lbs per cup

Not compatible with: curved surfaces (flat only); rough, textured, or porous surfaces; surfaces contaminated with oil, wax, or debris.

Technical Specifications

Specification	Details
Model	LP6HG
SKU	91337
Vendor	Wood’s Powr-Grip
Pack Quantity	2 cups (matched pair)
Load Capacity	70 lbs [32 kg] per cup / 140 lbs [64 kg] combined
Pad Diameter	6″ [15 cm]
Pad Model	LP6
Rubber Type	Standard
Handle Type	Aluminum (Handi-Grip)
Plunger Type	Industrial-Grade Plastic
Surface Texture Required	Smooth
Material Porosity Required	Nonporous
Allowable Surface Curvature	Flat only
Maximum Elevation	5,000 ft [1,500 m]
Operating Temperature Range	0°F to 120°F [-18°C to 49°C]
Vacuum Loss Indicator	Yes (red-line) — one per cup
Includes	Durable carrying case (fits both cups)

Safety Data Summary

• Always lift and lower simultaneously on a coordinated signal when using both cups on a single panel — uncoordinated lifting can overload one cup beyond its 70 lb rating
• Vacuum loss during a lift can result in sudden load drop, causing serious injury or property damage
• Do not exceed 70 lbs (32 kg) per cup
• Flat surfaces only — do not use on curved surfaces
• Damaged or contaminated suction pads must be replaced before use
• In cold environments, verify pad flexibility above 0°F (-18°C) before use
• Do not use above 5,000 ft (1,500 m) elevation
• Safety glasses or face shield, cut-resistant gloves, and steel-toed footwear required

Frequently Asked Questions

Q: What is the difference between the LP6HG2B and the LP6HG Pack of 4 (SKU 91335)?
A: Both use the same LP6HG cup — same LP6 pad, aluminum Handi-Grip handle, plastic plunger, 70 lb capacity, 0°F rating, and flat-only surface rating. The LP6HG2B is a matched pair of 2 cups with a durable carrying case, designed for two-person coordinated lifts as a dedicated matched set. The LP6HG Pack of 4 (SKU: 91335) provides four cups with vacuum pad protectors, suited for higher-volume operations. Choose the LP6HG2B for a dedicated two-cup field kit with carrying case; choose the Pack of 4 for higher-volume operations.

Q: What is the difference between the LP6HG2B and the LP6RH2B?
A: Both are matched pairs of 2 LP6 family cups with carrying cases and 70 lb / 0°F / flat-only ratings. The LP6HG2B uses a Handi-Grip handle optimized for versatile positioning across windshields, stone tiles, and sheet materials. The LP6RH2B uses an offset fixed handle that prevents load swing — the correct choice when load orientation must be controlled during the lift. LP6 replacement pads are interchangeable between both models.

Q: Is this product made to order?
A: Yes. This product is made to order and all sales are final. Please confirm your surface type, load requirements, and operating environment before placing your order.
